OX Electric Skateboard
- Battery: 16S (67.2V) — 1382Wh (OX) / 1728Wh (OX ER)
- ESC: Customized Hobbywing FOC with APP — 100A (180A phase)
- Tires: 160×55 (6in) pneumatic (OX) / 160×70 NEXT racing slicks (OX ER)
- Hubs: CNC NEXT Quick Release Hub (OX ER)
- Motors: Dual Linnpower 6487 motors
- Top Speed: 65 km/h | 40.4 mph
- Range: Up to 74 miles / 120 km* (with 125mm wheel)
*Range varies with rider weight, terrain, and riding style.
| AT BOARD | OX | OX ER |
| WHEELS | 160*55 6in Street Wheel | 160*70 NEXT Racing Slicks |
| RANGE | Up to 65km | 39 miles | Up to 85km | 51 miles |
| TOP SPEED | 65kmh | 40mph | 65kmh | 40mph |
| BATTERY | 16S6P EVE 40P, 1382WH, Featuring TOLL-packaged MOSFETs offering higher power and lower heat generation | 16S6P Samsung 50s, 1728WH, Featuring TOLL-packaged MOSFETs offering higher power and lower heat generation |
| BATTERY ENCLOSURE | Made from 6061 aluminum alloy, precision CNC machined, with an anodized finish | |
| MOTOR | Custom LINNPOWER 6487 ×2, 8000W total (board limit), 170KV — each motor rated at 8000W (16,000W total) | |
| ESC | Customized Hobbywing 16S FOC ESC & App | |
| REMOTE | Linnpower x Hobbywing Remote: CNC Aluminum Alloy Frame, and CNC Scroll Wheel, Double Bearing Fixation for Precise Control | |
| Board Size | 1150*395*180mm | 45.28*15.55* *7.09inches | |
| DECK MATERIAL | Premium skateboard deck featuring bamboo & Hard Maple wrapped in fiberglass and epoxy for exceptional strength and durability | |
| DECK Type | Deck features angled design, with 8° downward at the rear and 8° upward at the front | |
| DECK Size | 96*27.5cm/37.80*10.8inches | |
| TRUCK | LINNPOWER REAL Forged TKP trucks: 5-axis CNC-machined mounts, anodized finish, 10mm chromoly axle | |
| GEAR RATIO | Stock ratio: 4.3 * With 13T motor gear/Seperate purchase: 3.614:45, 3.2 | |
| WHEEL BASE | 950mm | 37.4 inches | |
| WEIGHT | 20.7kg | 45.6lbs | 21.7kg | 47.8lbs |
| MAX LOAD | 150kg | 330lbs | |
| CHARGE | 3.5h / 8A | 4h / 8A |
| HILLS | 55% | 55% |
| BREAKING | Regenerative Braking, adjustable 10-100% | |
| BEARING | 16100 bearings for the wheels | |
| BUSHING | 99a | |
| GripTape | OS780 Padded Griptape | |
| * Tested by a 154lbs/70kg rider at a constant speed of around 25 km/h | 15 mph, on flat terrain with gentle breeze at a temperature of 30℃/ 86°F. | ||
LINNPOWER OX All Terrain Electric Skateboard
The LINNPOWER OX is engineered for riders who demand extreme power, precision handling, and long-range performance. Equipped with dual LINNPOWER 6487 high-performance motors, a 16S 100A controller, and a pure aluminum battery enclosure for superior heat dissipation and durability, the OX delivers unmatched acceleration — reaching 30 mph in just 3 seconds.
Choose between 160×55 pneumatic tires (OX) or 160×70 LINNPOWER NEXT Racing Slicks (OX ER), both paired with our LINNPOWER NEXT Quick Release Hub — a best-selling design known for its strength, reliability, and easy maintenance. The CNC-forged all-aluminum split angle trucks and precision-designed deck geometry ensure exceptional carving stability and responsive control even at top speeds.
The all-new All Steel V4.3 2IN1 3-Gear Drive is smaller, lighter, stronger, and more adaptable than ever, delivering efficient power transfer with minimal noise.
Whether you’re conquering forest trails or cruising city streets, the OX blends power, durability, and control like no other board in its class. Built to ride farther, push harder, and stay cooler — this is the ultimate high-performance all-terrain board.
LINNPOWER OX Electric Skateboard Package Includes:
LINNPOWER OX or OX ER Complete Board;
LINNPOWER x Hobbywing Remote;
T Tool;
H4 Hex Key;
H3 Hex Key;
H2.5 Hex Key;
67.2V 8A Charger;
Remote Charge Wire: Type-C. Please make sure to use the original (stock)
charging cable to charge the remote, and avoid using fast chargers;
Remote Manual;
Quick Start Guide;
Precision Forged for Maximum Strength
REAL CNC T6 & Forged Truck
The LINNPOWER OX Truck hanger is fully forged from a single block of high-strength aluminum, commonly used in race car field, offering superior durability. And the baseplate is made from 6061-T6 aluminum.
Unlike traditional cast, the OX Truck is CNC'd in a single process using 5-axis technology, ensuring precise alignment and structural integrity. The anodized finish enhances corrosion resistance, keeping it strong and reliable in all conditions. With 130% more strength than regular cast trucks and 66% more than gravity-cast versions, the OX Truck is built for high-performance street and freestyle riding, delivering exceptional control, stability, and durability.
Maximum Strength & Durability
Kingpin & Axle
The LINNPOWER kingpin and axle are made from forged Chromium-nickel alloy steel , CNC-machined, heat-treated, and electroplated for superior strength and break resistance. Unlike standard cast trucks, our fully replaceable kingpin and axle provide higher durability and easy maintenance, ensuring long-lasting performance for aggressive riding styles. Traditional knurling and hex head designs often weaken over time, leading to instability and breakage. LINNPOWER has engineered a new fastening structure that eliminates these weak points, preventing loosening and ensuring a secure, high-performance ride.
Compared to regular cast components:
82% stronger than standard cast kingpins stronger than standard cast axles
Ride further than ever before
Up to 110KM
Similar to standard industry designs but built with a higher level of quality and attention to detail.
Extended Range: the 21700 Li cells, 16S architecture with 8A fast charging, delivering exceptional long-distance performance; Secure Construction: Individually secured cells in dedicated holders; 704 silicone bonding + 0.2mm pure nickel welding; High-Performance BMS: TOLL-packaged MOS for low heat, high efficiency, and compact design; Rigorous Standards: Exceeds industry quality benchmarks for reliability;
Built for endurance and reliability, the OX battery pack delivers long-range power and lasting performance for all-terrain electric skateboards.
Fast Charge. Faster Ride.
From 0-30mph: IN 3S
The OX series features a 16S high-voltage configuration with support for up to 10A fast charging, delivering shorter charge times and stronger power output under heavy loads. Although the OX and OX ER use different battery cells, both models can accelerate from 0 to 30 mph (48 km/h) in just 3 seconds, offering instant torque and an adrenaline-pumping riding experience.
We don’t need to push the throttle to the max—just a burst of acceleration is all it takes to overtake with confidence.
Stock Charger: 8A Fast Charger
Powerful & Smooth
Hobbywing 16S 100A FOC ESC
Hobbywing FOC ESC with App.
Extreme Power – Delivers up to 180A phase current, enabling explosive acceleration from 0–30mph in just 3 seconds.
CNC Aluminum Housing – Precision-machined casing with superior heat dissipation and a premium look, outperforming standard cast housings.
Built for Endurance – Optimized for long-distance cruising with exceptional reliability and stability.
Superior Hardware – Uses stronger, more durable materials and components, ensuring better performance compared to other controllers in its class.
With unmatched power delivery, premium build quality, and reliable performance, this custom Hobbywing controller is the ultimate choice for high-performance all-terrain electric skateboards.
Built Strong. Driven Fast.
High-Performance LINNPOWER Motors
Equipped with the powerful 6487 motor, engineered to deliver exceptional torque and all-terrain performance. It features a 10mm shaft compatible with both 3mm keyways and D-shaped couplings for a secure and versatile fit. A rear-mounted cooling impeller and front micro-vent system ensure efficient heat dissipation while protecting internal components from sand and debris. The flange shaft is reinforced with five YFS 12.9-grade M4 screws, providing unmatched structural strength and preventing loosening or damage during intense riding.
Inside, high-temperature N45SH magnets are secured with thickened stainless steel retaining rings and adhesive-filled slots to ensure long-term magnetic stability under extreme performance. Kawasaki 0.2mm silicon steel laminations minimize iron loss for maximum efficiency, while the rotor is dynamically balanced beyond 10,000 RPM — far exceeding standard 8,000 RPM motors — delivering smooth, reliable, and consistent power output.
Compact, Quiet, and Built to Last
ALL STEEL, 2in1 V4.3 3G
The 2in1 V4.3 3Gear Drive features a precision CNC-machined 6061-T651 aluminum housing, delivering enhanced performance, reduced noise, and superior impact resistance. Equipped with ultra-precise hardened steel gears for maximum durability, it supports dual gear ratios — 11T (stock) and 13T (optional) — allowing riders to fine-tune between torque and top speed. With five protective seals guarding against dust and water, and CNC-machined aluminum connectors reinforced with custom buffer rubber, this gearbox ensures exceptional efficiency, smooth power transfer, and long-term reliability.
Compared to the V4.3 AT/MT version, the 3Gear Drive is 45% smaller, 12% lighter, and an impressive 470% stronger — making it the ultimate choice for performance-driven riders.
Ride Hard. Stay Strong
High-Quality Performance Deck
OX’s deck is designed for a low, stable ride with smooth drop-down contours and ergonomic U-concave foot pockets—delivering comfort and easy maneuverability in every carve.
- Material Excellence: Crafted with Canadian Maple, Bamboo, and Fiberglass for enhanced strength and durability. (Lower-quality decks typically lack fiberglass reinforcement). - Epoxy Resin & High-Pressure Manufacturing: Unlike inferior decks that skip epoxy resin, our high-pressure molding process ensures superior bonding, increased durability, and long-lasting flex characteristics. - High Resilience & Durability: Built to withstand intense riding conditions without easily losing shape or performance over time.
Responsive Front. Confident Back.
Precision Design for Speed and Control
The OX deck features an asymmetric angle design: the front deck angle is increased for better carving and responsive turns, while the rear deck angle is slightly lowered to maintain high-speed stability and smooth tracking. Compared to standard longboards, the OX deck has a wider platform with reduced concave edges and a slightly lower standing area, enhancing comfort, control, and confidence during long rides or fast cruising.
Perfect for commuting, long-distance rides, and high-speed adventures, the OX deck keeps you in control on any terrain.
LINNPOWER Custom Pivot Cup
The standard pivot cups available on the market do not meet our precision requirements and fail to perfectly align with the base and the pivot point. Therefore, we have custom-made a pivot cup using better materials.
It offers better durability, with at least a 30% increase in lifespan compared to standard pivot cups. Additionally, the top vent design helps eliminate any noise, ensuring smoother performance.
OTHER FEATURES
6061-T6 Aluminum Heat Sink
The heat sink is CNC-machined from 6061-T6 aluminum alloy with an anodized surface, offering superior heat dissipation and a high-quality finish. Unlike cast components, this precision-machined design ensures better thermal performance and a sleek, durable appearance.
Full Aluminum Battery Enclosure
The battery enclosure is made from solid aluminum alloy, offering excellent heat dissipation, outstanding durability, and scratch resistance for long-lasting performance.
LINNPOWER x JECNN Customize Remote
CNC machined aluminum alloy frame, and CNC Scroll Wheel, with double bearing fixation for precise control.
OX ER Tires & Hubs – Maximum Grip, Effortless Swap
The OX ER comes with our 160*70 NEXT Racing Slicks, delivering exceptional traction and superior performance. It features wide quick-release hubs and the LINNPOWER best-selling Quick-Release Hub, making wheel changes hassle-free while maintaining stability, reliability, and top-tier ride experience.
OX Tires & Hubs – Grip Meets Convenience
The OX is equipped with 160×55mm (6-inch) pneumatic tires, offering excellent traction, superb durability, and a smooth, stable ride across all terrains. Paired with the LINNPOWER best-selling Quick-Release Hub, wheel changes become effortless — combining performance, reliability, and convenience in one package.
