Use code LPB20 for extra savings!
LINNPOWER Mini 5 Electric Shortboard
- 12s • 50.4V • 388Wh 21700 battery
- ESC: Customized Hobbywing FOC ESC with APP
- Wheels: 85mm Boosted urethane wheels
- Drive: Dual Hobbywing 5250 belt drive
- Top speed: 46 km/h | 28.5 mph
- Range: Up to 24.8 miles | 40 km*
*Range varies with rider weight, terrain, riding style, and environmental conditions.
Shipping
Note
| LINNPOWER | MINI 5 |
| WHEELS | Boosted 85*59mm, 78a |
| RANGE | Up to 35-40km | 21.7-24.8miles |
| TOP SPEED | 46kmh | 28.5mph |
| BATTERY | 12S2P 45E, 388Wh with secure, high-quality construction using silicone bonding and nickel welding |
| BATTERY ENCLOSURE | Made from high-strength polymer, paired with LINNPOWER's custom-designed reverse-mounted nut structure and sealing rings to enhance waterproofing |
| MOTOR | 5250*2, 1200W, 170kv |
| ESC | Hobbywing FOC ESC with App & Smart on/off |
| REMOTE | Hobbywig OLED remote |
| Board Size | 797*288*165mm | 31.4*11.34*6.48inches |
| DECK MATERIAL | Bamboo & Hard Maple wrapped in fiberglass and epoxy for exceptional strength and durability |
| DECK SIZE | 80*25cm | 31.5 *10 inches |
| DECK TYPE | A slightly concave deck with flared wheel wells with extended kicktail |
| TRUCK | Gravity Cast 8-inch, 45° |
| GEAR RATIO | 14:36, 2.6 |
| WHEEL BASE | 54.7cm | 21.5 inches |
| WEIGHT | 8.7kg | 19.18lbs |
| MAX LOAD | 150kg | 330lbs |
| CHARGE | 6h / 1.5A |
| HILLS | 25% |
| BRAKING | Regenerative Braking, adjustable 10-100% |
| BEARING | 608 bearings for the wheels, 6903 bearings for the pulley |
| BUSHING | 95a | Compatible with Riptide bushings (25×16mm) and washers |
| Light Kit | Integrated Tail Light, controlled by remote. |
| * Tested by a 154lbs/70kg rider at a constant speed of around 25 km/h | 15 mph, on flat terrain with gentle breeze at a temperature of 30℃/ 86°F. | |
LINNPOWER MINI 5 — Built to Go Far
The LINNPOWER MINI 5 is designed around one clear goal: maximize real-world range in a compact, belt-drive mini board. It’s built for riders who want to ride farther on a single charge — not chase peak power or aggressive performance.
In a market dominated by hub-driven shortboards with limited range, LINNPOWER MINI 5 stands out by combining a large-capacity battery with the natural torque and smoothness of a belt-drive system.
What Makes the MINI 5 Different
Long-Range Battery, Mini Board Form
MINI 5 is powered by a 388Wh battery built with 21700 lithium cells. That capacity is uncommon in this size category and allows riders to cover significantly longer distances than most mini boards without planning mid-ride charging.
For commuters and longer urban routes, fewer charging stops simply mean less friction in daily riding.
Belt Drive — More Torque Than Hub Motors
Unlike hub-driven mini boards, the MINI 5 uses a dual belt-drive system. Belt drive delivers stronger low-speed torque, smoother acceleration, and better control on inclines — especially noticeable when carrying a backpack or riding on varied terrain.
This makes MINI 5 a practical choice for riders who want consistent pull and predictable braking, rather than the on-off feel common with many hub systems.
Proven Components for Everyday Use
MINI 5 uses well-established, industry-proven components selected for reliability and ease of ownership. The gravity-cast trucks and Hobbywing electronics provide a familiar, dependable riding experience that many riders already trust.
Boosted Urethane Wheels
The board comes equipped with 85mm 78A urethane wheels from the original Boosted production line, known for their grip and comfort on imperfect pavement — ideal for longer rides where fatigue matters.
Who the MINI 5 Is Built For
- Riders who prioritize range over peak power
- Daily commuters who want fewer charging stops
- Those who prefer belt drive feel but don’t need a premium performance setup
- Riders looking for maximum value in a long-range mini board
If your priority is riding farther with confidence and simplicity, the LINNPOWER MINI 5 is built exactly for that purpose.
LINNPOWER Mini 5 Electric Shortboard Package Includes:
LINNPOWER Mini 5 Complete Board;
Hobbywing OLED Remote;
T Tool;
H3 Hex Key;
H2.5 Hex Key;
50.4V Charger;
Remote Manual;
Quick Start Guide;
Let customers speak for us

Re-Designed Deck for Enhanced Control
The LINNPOWER MINI 5 comes with the same deck of VIPER, the deck compares to standard Boosted boards with its extended kicktail for stability and control, plus a slightly concave design with flared wheel wells to prevent wheel bite, providing better control and a lower center of gravity for stable high-speed rides and agile low-speed maneuvers. While its cost is higher than some of other brands, it delivers better performance and durability.
* The top layer of the MINI 5 deck features a bamboo natural color.

Large-Capacity Battery 388Wh
Similar to standard industry designs but with a higher level of quality and attention to detail.
Extended Range: Built for riders needing long-distance performance with a more competive price;
Performance: 27A continuous discharge, offering solid power for long-range use (2S config); Secure Construction: Individually secured cells in dedicated holders; 704 silicone bonding + 0.2mm pure nickel welding; Rigorous Standards: Exceeds industry quality benchmarks for reliability;
The MINI 5 12S2P 21700 Li Battery 45E main advantage is offering the highest capacity in its price range, making it the top choice for riders seeking maximum range.

Hobbywing FOC ESC
Hobbywing FOC ESC with App. Equipped with a CNC-machined casing for improved heat dissipation, unlike casting, provides better heat dissipation and a higher-quality appearance. Considering the overall electrical configuration and reliability of the VIPER shortboard, the Hobbywing is the best choice. Its hardware is superior to other controllers in the same class, offering more solid and durable materials.

Hobbywing 5250 Motor*2
Hobbywing motors stand out in their class with smaller size, higher performance, and greater reliability at the same power level. For boards using a Hobbywing ESC, if the combined power is advertised as over 3500W, it means the specifications are overstated.

Heatsink - No Casting
For ESC housing and heatsink, while casting can offer a lower cost. But reliability is our top priority. CNC machining from 6061-T6 aluminum alloy with an anodized finish, unlike casting, provides better heat dissipation and a higher-quality appearance.

Gravity Casting 8in 45° RKP
The MINI 5 truck are made from A356.2 aluminum alloy using gravity casting, with CNC'd rear clamp and chromium-nickel alloy steel kingpin and axle. Its strength surpasses standard cast truck and follows similar manufacturing processes as Evolve Diablo series with Super Carve 2 truck hanger. The MINI 5 truck comes from the same supplier as these brands but with higher strength kingpin & truck axle than most similar boards.
OTHER FEATURES

Compatibility - Riptide Bushings
Designed to work with Riptide bushings(25×16) and washers for a more customizable ride feel.

Battery Enclosure
Made from high-strength polymer, paired with LINNPOWER's custom-designed reverse-mounted nut structure and sealing rings to enhance waterproofing.

Intergrated Tail Light
The Viper mini board comes standard with a tail light
integrated into the truck riser pad, protecting it from external damage. It
features high brightness for enhanced safety during nighttime riding.
FAQ
Most Powerful in its Class: 1200W dual belt-drive motors deliver the best torque and hill-climbing for under $450.
Long Range: Massive 388Wh battery provides 24.8 miles per charge—nearly double the competition.
Best Deck Quality: Built with premium materials typically reserved for $800+ boards.
Smooth Control: Equipped with a Hobbywing ESC for silky-smooth acceleration and reliable braking.
Pro Wheels: Authentic 85mm 78A Boosted production line wheels for the ultimate grip and ride comfort.
Portable & Tough: The ultimate 2026 mini-skate for commuters and students.
Riders Focused on Control: Perfect for those who prioritize handling and technical skill over extreme speeds or aggressive riding. The dual belt-drive offers the torque needed for city streets, parks, and campus inclines with superior maneuverability.
Trick & Performance Enthusiasts: Featuring an extended kicktail, the MINI 5 deck is engineered for better balance and pop, making it highly playable and responsive for kicks and turns.
Daily Commuters: Ideal for short-to-medium commutes. While the standard charger is optimized to extend battery lifespan, it is fully compatible with fast chargers (sold separately) for those on the go. Considering its range, it’s a lightweight option that’s easy to carry.
Value Seekers: If you want a belt-drive board in the $400 range, the LINNPOWER MINI 5 is the smartest choice for quality and performance in 2026.
The LINNPOWER MINI 5 features the same premium deck—a quality standard rarely seen in the $400 price bracket.
- Enhanced Control: Inspired by the legendary Boosted board, it features an extended kicktail for superior balance and effortless kick-turns.
- Precision Engineering: A subtle concave design with flared wheel wells eliminates wheel bite while lowering your center of gravity.
- Stability Meets Agility: Whether carving at high speeds or navigating tight campus corners, this deck offers a more stable, responsive, and durable ride than any other budget brand.
Unlike the common 2.1 or 2.0 gear ratios, the LINNPOWER MINI 5 comes with a stock 2.6 gear ratio, providing increased torque and enhanced climbing ability, making steep hills effortless.
The LINNPOWER MINI 5 is compatible with wheels ranging from 80mm to 105mm. The stock pulley is designed for kegel core. However, using larger wheels may increase the likelihood of wheel bite. If you plan to purchase Cloudwheels, you're going to be purchase our ABEC pulleys.
High-quality standard griptape offers a more direct connection between our feet and the board, providing better control. Additionally, premium griptape is more durable. The VIPER also features high-quality Boosted V3 wheels, which provide excellent shock absorption. However, if you prefer padded griptape, you can purchase it directly from LINNPOWER at low cost.
Firstly, any malfunctions caused directly or indirectly by water damage are not covered under our warranty.
However, thanks to LINNPOWER's reverse-threaded nut structure, silicone seal, etc., the LINNPOWER MINI 5's water resistance can reach an IP67 rating. The waterproof design is intended to handle unexpected situations, but please avoid riding in the rain or humid environments.
We offer a 6 month warranty. for more details please refer to our warranty policy.
