Motor
Important: After installing a new motor or ESC, please run the motor auto-learning procedure again.
Motor auto-learning tutorials:
OX / EVO MK-1 / VIPER / Linnpower MINI 5:
Watch Tutorial
Zephyr / THE ONE / OVERLAND:
Watch Tutorial
Shipping
USA, CA, EU, AU, UK: $15 flat shipping fee | Incl. Tax;
NOTE
Linnpower BOARDS Motor Specs
| Model | Connector | Motor Specs |
|---|---|---|
| Viper | Julet 9-Pin | HW5250 - 190KV |
| MINI 5 | MR30 | HW5250 - 170KV |
| Zephyr Base | MR60 | LP5250 - 170KV |
| Zephyr Pro | MR60 | LP6358 - 170KV |
| Zephyr Max V1* | Linnpower x ACEDECK Connector | DXW6374 - 170KV |
| Zephyr Max V2* | Linnpower x ACEDECK Connector | LP6475 - 170KV |
| THE ONE Select / Pro V1* | M6 6-Pin | LP6487 - 170KV |
| THE ONE Select / Pro V2* | M6 6-Pin | LP6487 - 170KV |
| THE ONE Prime V1* | M6 6-Pin | LP7087 - 170KV |
| THE ONE Prime V2* | M6 6-Pin | LP7087 - 170KV |
| OVERLAND 2WD | Linnpower x ACEDECK Connector | LP7087 - 170KV |
| OVERLAND AWD | Linnpower x ACEDECK Connector | LP6485 - 160KV |
| OX | MR60 | LP6487 - 170KV |
| EVO MK-1 V1* | Linnpower x ACEDECK Connector | HW6370 - 155KV |
| EVO MK-1 V2* | Linnpower x ACEDECK Connector | LP6475 - 155KV |
V1 and V2 motors are not interchangeable. V1 systems require V1 motors, and V2 systems require V2 motors. Upgrading a V1 system to V2 motors requires replacing both motors together.
Not sure which version you own?
Send us a photo of your motor & connector or board serial number before ordering.
High-Performance LINNPOWER Motors
Equipped with two powerful models, the 7087 and 6487, delivering exceptional torque for extreme racing. Featuring a 10mm shaft compatible with both 3mm keyways and D-shaped shaft for versatile fitment. Rear-mounted cooling impellers and front micro-vents provide efficient heat dissipation and protection against sand and dirt. The flange shaft is secured with five YFS 12.9 grade M4 screws, ensuring unmatched structural strength and preventing loosening or damage. Magnets use high-temp N45SH material, reinforced by thickened stainless steel retaining rings and adhesive-filled slots, guaranteeing long-term magnet stability under high performance. Kawasaki 0.2mm silicon steel laminations minimize iron loss, boosting efficiency. Dynamically balanced beyond 10,000 RPM — well above standard motors capped at 8,000 RPM — for smooth, reliable power delivery.
